DJ-200P Glue Dispensing Robot
4 ( P/N: W00588 )

Mobel:  DJ-200P
● MOQ :  1set
● Packing details:  1 set / carton
● Payment Terms:  T/T in advance, Paypal, Western Union

Qty:

  • Product Details
  • Reviews

Glue Dispensing Robot

Our glue dispensing robot has high performance and cost-effective platform, the working process is flexible and fast. The dispensing velocity, time, angles and dispensing volume, etc can be control as desired. It is suitable for various glue dispensing control, replace the manual dispensing operation, to realize the automatic dispensing, it improves the production efficiency, stable quality, and keep the dispensing process consistency. It can repid recovery cost.


Specifications:
Model
DJ-200P
Voltage
110V / 220V AC
Drive Mode
3-Axis precision step motor
Operating Range (X * Y * Z)
200 x 200 x 80mm
Movement Speed
X * Y * R Axis: 0.1~800mm/sec, Z Axis :0.1~400mm/sec
Repeatability  Accuracy
±0.002mm (X * Y * Z)
Minimum Analysis
0.01mm (X * Y * Z)
Maximum Load Weight
8kgs (for work platform)
Program Capacity
Max 255 Programs
Operate Temperature
10℃~40℃
Operate Humidity
20~90%
External Dimensions
380mm x 410mm x 630mm
Weight
about 31kgs































Features:

1.Replace the human labor and save labor cost.
2.Simple and convenient operation, high speed and precise control.
3.Realize the precise dispensing by the high-precision motor.
4.High performance Linear structure platform with nice appearance.
