Features:
1.For measuring the torque setting of electric screwdrivers, torque drivers and torque wrenches; for many other applications for
which jig tools are devised.
2.For collecting data on holes diameters prepared for tapping screws;
3.For controlling bottle cap fastening;
4.For testing breakdown of small parts;
5.For quality control of plastic screws and parts.
| Model | HP-10 | HP-50 | HP-100 | |
|
Measurement Range |
Kgf.cm |
0.15-10.00 |
1.5-50 | 1.5-100 |
| N.m | 0.015-1.0 | 0.15-5 | 0.15-10 | |
| Lbt.in |
0.15-9.00 |
1.5-45 | 1.5-90 | |
| Accuracy | within±0.5% | |||
| Power Source | 1.2V Nicd cell x 5 | |||
| Recharging Time | 8 hours with exclusIve charger | |||
| Continuous use at full charge | 30 hours | |||
| Dimensions (mm) | 230 (W) x 123 (D) x 65 (H) | |||
| Battery Life | chargeable for 300 times or more | |||
| Weight | 1.8 kg | |||
| Exclusive Charger | Input: AC220-240V Output: DC7.2V,120mA | |||
